STAINLESS STEEL SPRAY WASH CABINET
SINGLE PHASE, 208-240VAC, 60HZ

MODEL STW-50030SV

3.0 HP Stainless Steel Vertical Water Pump.

Warranty: One (1) year parts warranty, two (2) year pump warranty, and five (5) years cabinet

The all-stainless steel design* greatly improves the rust and corrosion resistance of the machine, making the service life of the spray wash cabinet longer.

24V AC control panel power
Internal dimensions: 30” turntable; 38” job height; 1,250 lbs. max weight capacity
Low water level alarm and automatic Shut-off protect heating elements and water pump against low water levels
Broken heater alarm and automatic shut-off
Stainless steel oil skimmer allows longer use of solution whilst changing less frequently
Sprocket drive that won't rob you of water pressure like water driven models can tend to do
Slow 4-5 rpm gives a superior, more thorough cleaning performance over water driven models
3.0hp stainless steel Vertical pump that pumps a solid 68 gallons per min
65 gallons insulated solution tank provides an ample supply of water for extra heavy-duty parts
6 kW heating element heating solution up to a maximum of 194F (90C) in approx. 1 hour
Full opening gasket free door as gaskets will often perish with long term exposure to steam
Stainless Steel Removable tank fine filter screen allows for quick and easy cleaning and protects the water pump
Optional biodegradable, non-caustic, heavy duty powdered detergent. ​
Power requirement: 208-240V AC, Single phase, 60Hz, 50Amp

Shipping*:

Standard LTL shipping to commercial address in 48 continental states.
$85.00 ea. additional charge will be applied on home-based business, limited access, liftgate, inside delivery service, and etc.
Local pickup is not available now
Please see detail information at shipping option.


Features

Simple Operation
0-60 Minute Automatic Timer
0-15 Minute Oil Skimmer
Lower Water Level Sensor Alarm
Lower Water Automatic Shut Off
Turntable Jog Switch
Sprocket Drive Turntable
Stainless Steel turntable bearings
Stainless Steel Spray Nozzles
Stainless Steel Removable Fine Filter
Stainless Steel Removable Parts Basket
Stainless Steel Removable Parts Tree
Accommodates Engine Crane Loading
Gasket Free Door
Heavy Duty Polyurethane Casters
3.0hp Stainless Steel Vertical Pump
1,250 lb Capacity Heavy Duty Stainless steel Turntable
2.75mm thickness SS304 stainless steel cabinet and door

*all-stainless steel design excluding the steel pump cover and control panel box
* If any additional charge applied on the delivery, we will send a separate bill for that.
* Warning: CA Prop 65
